PRODUCTS
Ks
Dimensions
(HxWxD)
Ks-4: 650 x 680 x 400 mm
Ks-8: 650 x 950 x 400 mm
Ks-12: 650 x 1220 x 400 mm
Ks-16: 650 x 1490 x 400 mm
Ks-20: 650 x 1760 x 400 mm
Ks-24: 650 x 2030 x 400 mm
Weight
Ks-4: Approx. 95 kg
Ks-8: Approx. 120 kg
Ks-12: Approx. 155 kg
Ks-16: Approx. 190 kg
Ks-20: Approx. 225 kg
Ks-24: Approx. 260 kg
Counting Speed 800/ 1,000/ 1,200 notes/minute
Hopper Capacity Max. 2,000 notes
Stacker Capacity
Max. 250 notes
4/ 8/ 12/ 16/ 20/ 24 pockets
Reject Capacity Max. 200 notes
Multi Currency Available
Number of currencies is dependent to currency combination and/or denominations
Options
PC Connections (LAN / RS-232C)
Printer Connection
Customer Display
Safe Pocket
Serial Number Recognition (Depends on Currency)
Division Card Function (Separate Card)
Additional Currencies
Function
Fitness Sorting
ATM Sorting
Value Count
Face
Orientation
Issue
Serial Number*
Division Card*
TITO*
( *Available for limited countries or currencies)
X10F
Dimensions
(HxWxD)
298 × 300 × 392 mm
Weight Approx. 15 kg
Counting Speed Up to 1200 notes/min.
Hopper Capacity Max. 500 notes
Stacker Capacity Max. 200 notes
Reject Capacity Max. 100 notes
Number of Currencies Up to 40 currencies
Display 5-inch Color Touch LCD Display
K4
Dimensions
(HxWxD)
700 x 700 x 400 mm
Weight Approx. 95 kg
Counting Speed Max. 900 notes/minute
Hopper Capacity Max. 1000 notes
Stacker Capacity
Max. 200 notes
4 pockets
Reject Capacity Max. 200 notes
Number of Currencies Up to 10 different currencies
Interface
RS-232C
Printer
Customer Display
LAN
Function
Fitness Sorting
ATM Sorting
Value Count
Face
Issue
Orientation
Serial Number Function (Option*1)
Division Card Function (Option*1)
TITO Function (Option*1)
(Option*1) Available for limited countries
K8
Dimensions
(HxWxD)
700 x 960 x 400 mm
Weight Approx. 130 kg
Counting Speed Up to 900 notes/minute
Hopper Capacity Max. 1000 notes
Stacker Capacity
Max. 200 notes
8 pockets
Reject Capacity Max. 200 notes
Number of Currencies Up to 10 different currencies
Interface
RS-232C
Printer
Customer Display
LAN
Function
Fitness Sorting
ATM Sorting
Value Count
Face
Issue
Orientation
Serial Number Function (Option*1)
Division Card Function (Option*1)
TITO Function (Option*1)
(Option*1) Available for limited countries
K12
Dimensions
(HxWxD)
730 x 1222 x 416 mm
Weight Approx. 185 kg
Counting Speed Upto 900 notes/minute
Hopper Capacity Max. 1000 notes
Stacker Capacity
Max. 200 notes
12 pockets
Reject Capacity Max. 200 notes
Number of Currencies Up to 10 different currencies
Interface
RS-232C
Printer
Customer Display
LAN
Function
Fitness Sorting
ATM Sorting
Value Count
Face
Issue
Orientation
Serial Number Function (Option*1)
Division Card Function (Option*1)
TITO Function (Option*1)
(Option*1) Available for limited countries
